Performance Aluminum Radiator, fits Mazda RX-7 1993-1995
The FD RX-7 is a unique sports car combining gorgeous body lines, a well-balanced chassis, and a high-revving rotary engine.Rotary engines are known to produce extreme temperatures under the hood, necessitating a reliable and efficient cooling system.Mishimoto has developed an all-new aluminum radiator specifically engineered for the 1993in2002 Mazda RX-7.Mishimoto radiators are constructed from durable aircraft-quality aluminum and feature 100-percent brazed aluminum cores.This radiator features TIG-welded end tanks polished to a flawless finish, producing a perfect blend of performance and style.The Mishimoto RX-7 radiator improves cooling efficiency and heat dissipation for the ultimate upgrade to extend the life of your 13B.This radiator exhibits factory fitment for an easy installation and includes the Mishimoto lifetime warranty.
- 100% all-aluminum construction
- Increased core size for additional cooling capacity over OEM
- TIG-welded for increased durability
- Retains OEM fitment
- Brazed aluminum core
- Polished aluminum end tanks
- Lifetime Warranty
Information:
Mazda Aluminum Radiator
Application Summary:
| Year |
Make/Model |
| 1993-1995 |
Mazda RX-7 |
| Attributes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Core Height |
12.3 |
| Core Length |
24.9 |
| Core Material |
Aluminum |
| Core Thickness |
1.03 |
| Country of Origin (Primary) |
CN |
| Down Flow Or Cross Flow Type |
Down Flow |
| Drain Plug Included |
Yes |
| Fluid Capacity |
2.6 |
| Harmonized Tariff Code (Schedule B) |
8708915000 |
| Hazardous Material Code |
N |
| Inlet Diameter |
1.5 |
| Inlet Location |
Top Right |
| Install Difficulty |
3 |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum |
| NAFTA Preference Criterion Code |
B |
| Outlet Diameter |
1.5 |
| Outlet Location |
Bottom Left |
| Overall Height |
17.2 |
| Overall Length |
25.5 |
| Overall Width |
5.12 |
| Radiator Cap Included |
No |
| SDR Required Flag |
N |
| SellingPoint01 |
100-percent all-aluminum construction |
| SellingPoint02 |
Increased core size for additional cooling capacity over OEM |
| SellingPoint03 |
TIG-welded for increased durability |
| SellingPoint04 |
Retains OEM fitment |
| SellingPoint05 |
Brazed aluminum core |
| SellingPoint06 |
Polished aluminum end tanks |
| SellingPoint07 |
Lifetime Warranty |
| SellingPoint08 |
N/A |
| SellingPoint09 |
N/A |
| SellingPoint1 |
100-percent all-aluminum construction |
| SellingPoint10 |
N/A |
| SellingPoint11 |
N/A |
| SellingPoint12 |
N/A |
| SellingPoint13 |
N/A |
| SellingPoint14 |
N/A |
| SellingPoint15 |
N/A |
| SellingPoint2 |
Increased core size for additional cooling capacity over OEM |
| SellingPoint3 |
TIG-welded for increased durability |
| SellingPoint4 |
Retains OEM fitment |
| SellingPoint5 |
Brazed aluminum core |
| SellingPoint6 |
Polished aluminum end tanks |
| SellingPoint7 |
Lifetime Warranty |
| SellingPoint8 |
N/A |
| SellingPoint9 |
N/A |
| TechSpec Applications |
N/A |
| TechSpec Chassis Codes |
FD3S |
| TechSpec Core Height (in) |
12.3 |
| TechSpec Core Length (in) |
24.9 |
| TechSpec Core Thickness (in) |
1.03 |
| TechSpec DPI |
1725 |
| TechSpec Drain Plug Thread Size |
M12 x 1.5 |
| TechSpec Engine Codes |
13B |
| TechSpec Fluid Capacity (gal) |
2.6 |
| TechSpec Includes |
Mishimoto Radiator--Mishimoto Lifetime Warranty--Magnetic Drain Plug |
| TechSpec Inlet (in) |
1.5 |
| TechSpec Material |
N/A |
| TechSpec Note |
N/A |
| TechSpec Outlet (in) |
1.5 |
| TechSpec Overall Height (in) |
17.2 |
| TechSpec Overall Length (in) |
25.5 |
| TechSpec Overall Width (in) |
5.12 |
| TechSpec Overall Width (ins) |
5.12 |
| TechSpec Rows |
1 |
| Transmission Oil Cooler Fitting Type |
N/A |
| Transmission Oil Cooler Included |
No |
| GTIN |
00748666008366 |
